222 4102 003 00
DIGITAL MULTIMETER 3940
|
|
|
|
Continue Shopping
|
Details
|
Product Weight:
0.35 kg
|
|
|
|
|
Description:
|
DIGITAL MULTIMETER features powerful automotive test functions such as; Frequency, Duty Cycle, Diode & Continuity Tests, plus all the standard meter features you expect in a professional grade Multimeter.
Features:
Diode Test
Continuity Test
Auto Range
Data Hold
Relative Change
Backlight
Relative Change
Min/Max
Auto Power Off
Technical Specifications:
Frequency: 1Hz ~ 10MHz ± 0.1%
Duty Cycle: 0.1% ~ 99.9% ± 2.5%
DC Volts: 400mV/4/40/400V ± 0.5%, 1000V ± 0.8%
AC Volts: 4/40/400V ± 0.8%, 400mV/750V ± 1.2%
DC Amps: 400/4000μA ± 2%, 40/400mA ± 1.5%, 4/10A ± 2%
AC Amps: 400/4000μA ± 2.5%, 40/400mA ± 2%, 4/10A ± 2.5%
Resistance: 400Ω/4/40/400kΩ ± 1%, 4/40MΩ ± 2%
Capacitance: 40nF ± 3.5%, 400nF/4μF/40μF ± 3%, 400μF/4000μF ± 20%
Dimensions (H x W x D): 17.7cm (H) x 8.8cm (W) x 3.9cm
|
|
|
